Capacity Empty Weight: 12,500 lbs. Gross vehicle weight: 18,000 lbs. Cubic capacity: 1167 cu. ft. Wheel wells in the box allow lowest possible deck height Features Air Conditioning AM / FM Radio Tire size: 245/70R/19.5 G Power Steering 4 wheel disc brakes Class three rear hitch, 2 inch ball rated for 5000lbs. towing weight Approximate MPG: 8 to 10 Fuel tank capacity: 60 gal. Rear door is a roll up type door Tinted Glass 145 AMP Alternator Heavy duty rear shock absorbers Rear leaf spring suspension Rub rails inside the box Fuel Engine: 7.4L V-8 Vortec Gas, 270 Net HP, 454 cu. In. Transmission: 4 Speed Automatic, Allison AT545 Differential & gear ratio: Eaton 1960S single speed axle / 4.66 Engine high temperature alert Engine alarm for low oil pressure Port injection fuel system Dimensions Box roofline inside: 24' Box floor inside: 20' Box inside width: 7' 7'', Inside height: 7' 1'' Box outside width: 8', Outside height: 11' Approximate box weight: 3400 lbs. Wheelbase: 229'' Loading ramp length: 8' 1" Loading ramp width: 31" Rear door opening height: 6' 10'' Rear door opening width: 7' 7'' Aluminum ramp on the rear: 7' 6'' X 29'' wide Cab to axle: 156", Cab to end of frame: 249"
|
