Estate Sale This mill is brand new, never used. Priced at Grizzly today is $7,650 not including shipping. Hubby passed away before he could use it.
G0695 8" x 30" 1-1/2 HP Variable-Speed Knee Mill with Ram Head This knee mill will be a fine addition to any home shop, school, or job shop! The G0695 8" x 30" 1-1/2 HP Variable-Speed Knee Mill with Ram Head runs on single-phase power using an inverter. Now you can have speeds from 200 to 2250 RPM with just the turn of a dial. The head slides in and out, swivels, and tilts 45° left-to-right, enabling extremely versatile operations. Features hardened and precision-ground leadscrews, dovetail ways, turret-style column, and fine downfeed on quill. SPECIFICATIONS:
Required power source: 220V, single-phase, min. 15A circuit
Motor: 1-1/2 HP, 220V
Spindle taper: R-8
Spindle travel: 3-1/2"
Spindle speed: Variable, 220–2250 RPM
Max distance spindle-to-table: 20"
T-Slots: 3 @ 1/2" wide, 2-3/16" centers
Table size: 8" x 30"
Longitudinal table travel (X-axis): 18"
Cross table travel (Y-axis): 7-1/2"
Vertical table travel (Z-axis): 17-3/4"
Head tilt: 45° left/right
Ram travel: 18"
Drilling capacity: 3/4" mild steel
Overall size: 42-3/4" W x 40-1/2" D x 79" H
Approximate shipping weight: 1006 lbs. FEATURES:
Variable frequency drive (VFD) for smooth, high-torque variable speed using single-phase power
Convenient one-shot lubrication system
High-precision ball bearings
Bronze nut on longitudinal and cross feed leadscrews
Variable-speed frequency drive allows speeds from 200 to 2250 RPM
Hardened and precision-ground leadscrews
Runs on single-phase power using an inverter
Cast-iron construction throughout machine Grizzly owner's manuals and instruction sheets are produced by our U.S.-based Technical Documentation Department and are packed with useful information.
Please, only inquire if you are truly interested in purchase.
|
